You - Coax - and Smith by Michael Toia is a practical guide designed to teach readers how to use the Smith Chart for analyzing and designing transmission lines in radio frequency (RF) and microwave engineering. The book emphasizes a hands-on, visual approach, reducing complex mathematics to simple geometric drawings.

📘 Book Overview*

This NEW 2017 78-page paperback, published by Jokalym Press, serves as a comprehensive introduction to the Smith Chart. It covers topics such as AC impedance measurements, transformations to polar coordinates, and applications like determining transmission line impedance and designing matching stubs. The author provides step-by-step instructions on constructing the Smith Chart from scratch using plane geometry.

🧭 Key Features

• Visual Learning: The book employs a sequence of drawings to explain concepts, minimizing the use of complex mathematics.

• Practical Applications: It includes real-world applications like impedance matching and stub design.

• Step-by-Step Instructions: Detailed guidance on drawing the Smith Chart from scratch.

📚 Chapter Breakdown

1. AC / DC
2. Coax And It's Impedance
3. Drawing A Smith Chart
4. Familiarization
5. Impedance Transformer Resistive Loads
6. Impedance Transformer General Loads Antenna Tuning
7. Cable Baluns
8. Zepps And J-Poles
9. Monopole And Dipole Shunts
10. Concepts Of Broadbanding
11. Zo
12. Appendix A - Phasor Arithmetic
13. Appendix B - The z - p Conformal Mapping
