Connectors - Type C
Type C Connector - The Type C connectors looks like a large BNC physcally. Many Geiger counter such as Ludlum types use this connector along with many radio devices.
HEX Crimp Die Sizes* for FERRULES for common RF Cables:
.429" - LMR-400, RG-8/11/213/214, Belden 8214/9913
.255" - LMR-240, RG-6/8X/59/62/223
.213" - LMR-195/200, RG-58/142/400
.178" - LMR-100/110, RG-174/178/188/196
*The hex sizes shown are nominal sizes, the user should always inquire if it is not known what size crimp is needed from the manufacturer of the connector. Connectors in this day and time do unfortunately vary in size.
The majority of our brand center RF pins are designed to be soldered and not crimped.
4 products
